Datalogic Magellan 3410VSi OEM Presentation Scanner (M3420-010230-00605)

The Datalogic Magellan 3410VSi OEM is the compact built-in version of the Magellan 3410VSi presentation scanner, designed for self-checkouts, kiosks and other OEM applications. It uses the same electronics and optics as the Magellan 3410VSi in a smaller, lighter housing (12.7 × 14.4 × 7.8 cm, 0.3 kg) whose integrated window mounts directly against the enclosure surface. Its 1 MP imager reads 1D and 2D barcodes from paper labels and phone screens, it powers from a single USB port, and it comes with a 3-year Datalogic warranty. This version, M3420-010230-00605, comes with a 2 m USB Type A cable – ready to plug into a PC or POS system; the power supply is not included (not needed for USB).

Key Features

• Advanced digital imaging – a 1 MP (1280 × 800) sensor processes up to 30 million pixels per second; the large field of view supports both fast sweep (1D sweep speeds up to 1.5 m/s) and presentation scanning, and even truncated, out-of-spec and poorly printed codes are read with ease.
• 1D, 2D and mobile codes – reads all standard 1D codes, GS1 DataBar, PDF417, Data Matrix, QR and Aztec codes from paper and phone screens at distances up to 20 cm; support for Digimarc digital watermarks is available as an option.
• Made for integration – the same electronics and optics as the Magellan 3410VSi in a smaller, lighter package; the integrated window allows the unit to be mounted directly against an enclosure surface for a clean, sealed installation.
• Powered by a single USB port – runs from one 5 V USB Type A connection (max. 2.25 W), so no external power supply is needed for USB installations.
• ScanSentry – uses the scanner's camera to detect scan avoidance at self-checkouts, and object sensing can even detect when a customer approaches the scanner.
• Multiple interfaces in every unit – USB Keyboard, USB COM, USB TEC, OEM (IBM) USB and RS-232; a configurable beeper and an external read indicator signal on the host connection provide good-read feedback inside the enclosure.
• Powered USB auxiliary port – for connecting an additional USB device (requires a power supply or 12 V host power; not enabled on a 5 V USB Type A host port).
• Enterprise features – image capture (BMP, JPEG), micro SD card slot, diagnostics reporting and remote management via OPOS, JavaPOS, Toshiba Remote Management (IBM Systems Director) and Wavelink Avalanche; configuration with Magellan Scanalyzer.
• Comfortable and reliable – subtle, adaptive illumination is easy on the eyes, solid-state electronics work silently, and a 3-year Datalogic factory warranty is included; EASEOFCARE service plans are available.

Ideal Applications

• Self-checkouts in supermarkets and retail stores
• Kiosks, information and ticketing terminals
• Point-of-sale counters and checkout furniture with a built-in scanner
• Mobile coupons, loyalty cards and mobile marketing
• Age verification by reading 2D codes on ID documents

All Magellan 3410VSi OEM Versions

The highlighted row is the version you are currently viewing.

Technical Specifications

Not sure which version you need? Both versions contain the same Magellan 3410VSi OEM scanner. Choose M3420-010230-00605 for a ready-to-use kit with a 2 m USB cable, or M3420-010230 if you need a different cable (for example OEM (IBM) USB or RS-232) or already have one. For a stand-alone counter scanner, see the standard Magellan 3410VSi (M3410-010200-00604). Compare other models in our Presentation Barcode Scanners collection or contact our team for volume pricing and integration support.
