| Katalogové číslo | TC5301-0T1K7B1000-A6 |
| Model | Zebra TC53 (Wi-Fi model of the TC53/TC58 series, Standard edition) |
| Operační systém | Android with Google Mobile Services (GMS); upgradeable to Android 16 |
| Procesor | Qualcomm 6490 octa-core, 2.7 GHz |
| Paměť (RAM / Flash) | 8 GB RAM / 64 GB UFS Flash |
| Rozšíření | User-accessible microSD slot, up to 2 TB |
| Displej | 6.0" Full HD+ (1080 × 2160), LED backlight, 600 nits, optically bonded to the touch panel |
| Dotykový panel | Multi-mode capacitive touch – bare or gloved finger or conductive stylus (sold separately); Corning Gorilla Glass; water droplet rejection; anti-smudge coating |
| Klávesnice | On-screen keypad and Zebra Enterprise Keyboard |
| Tlačítka | Dual dedicated scan buttons, dedicated push-to-talk button, volume up/down; trigger handle button via rear I/O |
| Snímací modul | SE55 1D/2D advanced range imager with IntelliFocus – from items in hand to over 12 m away; Corning Gorilla Glass exit window |
| Zadní fotoaparát | 16 MP autofocus with LED flash, torch mode and HDR |
| Přední fotoaparát | 8 MP |
| Wi-Fi | Wi-Fi 6E (IEEE 802.11a/b/g/n/ac/ax; 2.4, 5 and 6 GHz), 2x2 MU-MIMO, dual-band simultaneous; WPA3; fast roaming 802.11r / OKC / CCKM / PMKID caching |
| Bluetooth | Bluetooth 5.2, Class 2 |
| NFC | ISO 14443 A/B, FeliCa, ISO 15693; host card emulation; contactless payment support (ECP 1.0 / 2.0); Apple VAS certified, NFC Forum certified, Google Smart Tap ready |
| Mobilní data (WWAN) | Not available – Wi-Fi only (choose the TC58 for 5G) |
| GPS/GNSS | Not available (TC58 only) |
| Hlas a zvuk | 3 microphones with noise cancellation, dual speakers, speakerphone, Bluetooth headsets, USB-C PTT headset; HD Voice, Super-wideband and Fullband audio; PTT Express over Wi-Fi; 3.5 mm headset jack |
| Porty | USB-C (USB 3.0 SuperSpeed, host and client); rear I/O (USB 2.0 host) for trigger handle and accessories; 3.5 mm audio jack |
| Senzory | Light sensor, proximity sensor, 3-axis accelerometer with gyroscope, pressure sensor |
| Baterie | 4680 mAh / 18.01 Wh PowerPrecision+ Li-ion, user-replaceable (BTRY-NGTC5TC7-44MA-01); optional 7000 mAh extended battery; warm swap mode |
| Výdrž baterie | Full shift (standard battery) |
| Nabíjení | Via USB-C (cable + USB power adapter) or a charging cradle – not included; fast charging (0–90% in approx. 1.5 h in a cradle) |
| Provedení | Smartphone-style rugged touch computer |
| Rozměry | 164.8 × 77.35 × 16.75 mm (L × W × H) |
| Hmotnost | 293 g with standard battery |
| Odolnost proti pádu | Multiple 1.5 m drops to tile over concrete (−10 °C to 50 °C); multiple 1.8 m drops to concrete with protective boot across the operating temperature range (MIL-STD-810H) |
| Odolnost proti převalování | 1000 tumbles at 0.5 m; 1000 tumbles at 1.0 m with protective boot |
| Krytí | IP68 and IP65 (with battery) |
| Provozní teplota | −20 °C to 50 °C |
| Skladovací teplota | −40 °C to 70 °C |
| Vlhkost | 5–95% non-condensing |
| RFID | Via optional RFD40 / RFD90 UHF RFID sled (eConnex or Bluetooth adapter) |
| Software a správa | Zebra Mobility DNA: DataWedge, StageNow, Enterprise Browser, Enterprise Home Screen, Device Tracker, Device Diagnostics, PTT Express; LifeGuard for Android with Zebra OneCare; Workstation Connect |
| Barva | Black |
| Záruka | 12 months (Zebra 1-year hardware warranty); Zebra OneCare service plans available |
| Obsah balení | Zebra TC53 mobile computer (TC5301-0T1K7B1000-A6), standard 4680 mAh PowerPrecision+ Li-ion battery (BTRY-NGTC5TC7-44MA-01), Google Mobile Services (GMS) licence preinstalled, regulatory guide – charger/power supply, USB-C cable, charging cradle and hand strap NOT included (order separately) |
